5307-2RS - Chrome Steel - Sealed - Radial Ball Bearing - 1 17/45" x 3 3/20" x 1 3/8"

Original price $21.50 - Original price $21.50
Original price $21.50
$21.50
$21.50 - $21.50
Current price $21.50
Part Number: 5307-2RS
Series: 5300 Series
Type: Straight
Cage Type: Chrome Steel
Shield Type: Double Rubber Seal
Snap Ring: No
TECHNICAL SPECIFICATION
Dimension
D Outside Diameter
d Inside Diameter
B Width
Metric
N/A
N/A
N/A
Inches
3.1496
1.378
1.374
Load Ratings (lbs)
Dynamic: 10000
Static: 7160
CONTACT FOR MORE INFORMATION    or call us at (818) 988-1880

Introducing the 5307-2RS Ball Bearing from the 5200 Series - Double Row Metric, expertly engineered for precision and reliability. This high-quality ball bearing is perfect for a range of applications, ensuring smooth operation and durability. **Key Specifications:** - Part Number: 5307-2RS - Series: 5200 Series - Double Row Metric - Bore: 35 mm (1.378 in) - Outer Diameter: 80 mm (3.1496 in) - Width: 34.9 mm (1.374 in) - Material: Chrome Steel - Closure Type: Double Rubber Seal - Flange: Straight O.D - ABEC Rating: 1 (A3 through A9 available upon request) Crafted with precision engineering, this bearing is designed for optimal performance, offering reliability in demanding environments. With additional lubrication options available from our clean room facility, we ensure high standards are met. *If you don't find the bearing you're looking for or have special requests, please call us at 1-800-423-9000. We appreciate the opportunity to help you.*
